Commercial Seed Tenders

Features
Applications
Specifications
Accessories

Our commercial seed tenders have up to six stainless steel lined compartments. These heavy-duty tenders are designed to change the way you haul seed and fertilizer. Perfect for large operations or agri-retailers, our line of CST’s can reduce your downtime significantly while providing the versatility to use it year round.

Our trailer-mounted series are powered by a diesel engine, with self-contained hydraulics. They have a load capacity of up to 1,550 cubic feet and unload at a rate of 2 tons per minute.



Features Show / Hide more information

1. Tier 4, diesel engine
2. Up to 6 compartments
3. Stainless steel slave conveyor construction
4. Stainless steel slopes & gates
5. 12 gauge hopper construction
6. Two stage - epoxy/polyurethane coating system
7. 20” wide, slave conveyor belt
8. 25’ 7” long, 16” paddle belt, unload conveyor
9. Self-contained hydraulics
10. Aluminum anodized hydraulic valves
11. Camera package
12. LED gate indicators
13. Air ride trailer
14. Aluminum outer wheels with polyethylene fenders
15. LED working lights
16. Internal cat walk
17. External ladders
18. 2 sight glasses per compartment
19. Access holes

Applications Show / Hide more information

1.Seed
2.Grain
3.Fertilizer

Specifications Show / Hide more information

CST-1550 Model CST-1500 Model
Length N/A N/A
Width N/A N/A
Height*** N/A N/A
Discharge
Heights*** Min/Max
8’ 2” @ 15°
18’ 8” @ 40°
8’ 8” @ 15°
19’ 1” @ 40°
Swing Diameter 144° Swing
43’ 2” Reach
144° Swing
42’ 7” Reach
Empty Weight 25,060 lb 25640 lb
# of Comp. N/A N/A
Ft3 / Comp.
(Total)
258.5
(1551)
276
(1380)
Units / Comp. *
(Total)
320
(1920)
342
(1710)
Bushels / Comp.
(Total)
208
(1248)
222
(1110)
Compartment Capacity ** Imperial 8 Ton 8.6 Ton
Compartment Capacity ** Metric 7.3 MT 7.8 MT ea.
Total Capacity ** Imperial 48 Ton 43 Ton
Total Capacity ** Metric 43.6 MT 39 MT

Table is base on liquid measurements, and does not account for piling above the side walls.
* Units based on 50 lb/unit.
** Capacity based on 62 lb/ft3.


Accessories & Options Show / Hide more information

1.

Weigh scale package

2.

Chrome fenders
