16” Belt Conveyors
Model |
Axle Width |
Transport Height |
Transport Length |
Discharge Height (15 Degrees) |
Length (15 Degrees) |
Discharge Height (20 Degrees) |
Length (20 Degrees) |
Discharge Height (25 Degrees) |
Length (25 Degrees) |
Discharge Height (30 Degrees) |
Length (30 Degrees) |
1655 |
11′ 4″ |
9′ 9″ |
61′ |
13′ 5″ |
5′ 2″ |
18′ 4″ |
54′ |
23′ 2″ |
52′ 5″ |
27′ 9″ |
50′ 6″ |
1665 |
11′ 4″ |
10′ 8″ |
71′ |
16′ 2″ |
64′ 7″ |
22′ |
63′ |
27′ 4″ |
60′ 11″ |
32′ 8″ |
58′ 5″ |
1670 |
11′ 4″ |
11′ 10″ |
75′ 11″ |
17′ 4″ |
69′ 8″ |
23′ 6″ |
68′ 1″ |
29′ 6″ |
66′ 1″ |
35′ 3″ |
63′ 6″ |
1675 |
11′ 4″ |
12′ 5″ |
80′ 11″ |
18′ 9″ |
74′ 6″ |
25′ 3″ |
72′ 10″ |
31′ 7″ |
70′ 7″ |
37′ 8″ |
67′ 10″ |
1685 |
12′ 6″ |
11′ 7″ |
91′ 1″ |
21′ 5″ |
84′ 2″ |
28′ 9″ |
82′ 3″ |
35′ 11″ |
79′ 8″ |
42′ 9″ |
76′ 6″ |
1690 |
12′ 6″ |
12′ 2″ |
96′ |
22′ 7″ |
89′ |
30′ 4″ |
86′ 11″ |
37′ 11″ |
84′ 2″ |
45′ 3″ |
80′ 10″ |
16100 |
13′ 6″ |
14′ 7″ |
105′ 10″ |
25′ 3″ |
98′ 8″ |
33′ 10″ |
96′ 4″ |
42′ 2″ |
93′ 3″ |
50′ 2″ |
89′ 6″ |
22” Belt Conveyors
Model |
Axle Width |
Transport Height |
Transport Length |
Discharge Height (15 Degrees) |
Length (15 Degrees) |
Discharge Height (20 Degrees) |
Length (20 Degrees) |
Discharge Height (25 Degrees) |
Length (25 Degrees) |
Discharge Height (30 Degrees) |
Length (30 Degrees) |
2265 |
9′ 1″ |
11′ 5″ |
69′ |
15′ 1″ |
63′ |
20′ 7″ |
61′ 8″ |
25′ 10″ |
59′ 10″ |
30′ 11″ |
57′ 7″ |
2270 |
9′ 1″ |
11′ 7″ |
74′ |
16′ 10″ |
67′ 10″ |
22′ 9″ |
66′ 4″ |
28′ 6″ |
64′ 4″ |
34′ 1″ |
61′ 11″ |
2275 |
9′ 1″ |
11′ 2″ |
78′ 11″ |
17′ 8″ |
72′ 8″ |
24′ |
71′ 1″ |
30′ 1″ |
68′ 11″ |
35′ 11″ |
66′ 3″ |
2285 |
13′ 6″ |
12′ 4″ |
89′ |
20′ 9″ |
82′ 4″ |
27′ 10″ |
80′ 5″ |
34′ 8″ |
77′ 11″ |
41′ 3″ |
74′ 10″ |
2290 |
13′ 6″ |
13′ 1″ |
93′ 11″ |
22′ 1″ |
87′ 2″ |
29′ 7″ |
85′ 2″ |
36′ 10″ |
82′ 5″ |
43′ 9″ |
79′ 2″ |
22100 |
13′ 6″ |
14′ |
103′ 11″ |
24′ 8″ |
96′ 10″ |
33′ 0″ |
94′ 6″ |
41′ 0″ |
91′ 6″ |
48′ 9″ |
87′ 10″ |
22110 |
13′ 6″ |
14′ 6″ |
108′ 11″ |
27′ 3″ |
101′ 8″ |
36′ 5″ |
99′ 3″ |
45′ 3″ |
96′ |
53′ 9″ |
92′ 9″ |
- Collapsible hopper
- Full length windguards
- Heavy-duty scissor lift undercarriages
- Positive Pinch Drive Box
- 1. SWING OUT (SO) PACKAGE
- 360 degree swing allows the user to unload on either side of conveyor (no tractor in the way at
end of conveyor)
- Remote controlled swing can be placed into unload position with the push of a button
- Long reach for maximum accessibility
- 2. MOVER KIT (SP) PACKAGE:
- Our mover package takes convenience to a new level. Users can easily move large conveyors without hooking up to or tying up a tractor.
- 3. MOVER KIT (SP) PACKAGE:
- Stainless steel components
- Winch for collapsible hopper
- Hydraulic lift
Meridian Manufacturing warrants all new, unaltered tube conveyors intended for standard or on-farm usage against defects in material or workmanship for a period of one year from the date of purchase. For equipment used in commercial applications, Meridian provides a warranty against defects and workmanship for a period of 90 days.
For components not manufactured by Meridian, such as tires, engines, batteries, etc., please refer to the respective manufacturer for the applicable warranty information. Additional details can be obtained by contacting your authorized Meridian/Convey-All dealer or consulting your owner’s manual.
